Automatic Glass Bottle Beer / Carbonated Drink Beverage Filling
Machinery Prices
product description
This BGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used
to produce beer filling
machine. The BGF Wash-filling-capping 3-in-1unit:beer Machinery can
finish all the process such
as press bottle, filling and sealing, it can reduce the materials
and Outsiders touch time, improve
the sanitary conditions, production capacity and economic
efficiency.
1. Using the wind sent access and move wheel in the bottle directly
connected technology;
canceled screw and conveyor chains, this enable the change the
bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology,
bottle-shaped transform not need to
adjust the equipment level, only change related the curved plate,
wheel and nylon parts is
enough..
3. The specially designed stainless steel bottle washing machine
clip is solid and durable, no
touch with the screw location of bottle mouth to avoid secondary
pollution.
4. High-speed large gravity flow valve filling valve, filling fast,
filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no
need to adjust the height of
conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key
electrical components from
famous company such as Japan's Mitsubishi, France Schneider, OMRON.
technical parameter
| Model | Washing heads | Filling heads | Capping heads | Capacity(b/h) 500ml | Motor power (KW) | Overall dimension (mm) |
| BFG14-12-4 | 14 | 12 | 4 | 2000bph | 3.5KW | 2500x1700x2500 |
| BFG18-18-6 | 18 | 18 | 6 | 3000bph | 3.75KW | 2800x1900x2650 |
| BFG24-24-8 | 24 | 24 | 8 | 4000bph | 5.5KW | 3000x2100x2650 |
| BFG32-32-10 | 32 | 32 | 10 | 6000bph | 5.75KW | 3500x2500x2650 |
| BFG40-40-10 | 40 | 40 | 10 | 8000bph | 6.5KW | 4000x1800x2650 |
| BFG48-48-12 | 48 | 48 | 12 | 12000bph | 7.5KW | 4500x4500x3400 |
| BFG60-60-15 | 60 | 60 | 15 | 15000bph | 9KW | 5000x4500x3400 |
overall look
inner look
electrical system
Besides the monobloc, there is split beer machine
FAQ
Q: How should i do if meet some trouble while using?
A: Don’t worry about that, our professional solution and video will
send to you immediately.
Q: What about payment term?
A: T/T in advance, 30% deposit, 70% balance before shipment.
Q: What is the MOQ?
A: 1 set
Q: Can you do OEM & ODM?
A: Yes
Q: Where is your nearest port?
A: Shanghai Port
Q: Where is your factory located? How can I visit there?
A: Our factory is located in zhangjiagang City, China.You can fly
to shanghai airport directly.
If furthur lear, we will provide you more helpful information......
